Rana Group of Companies is launching new products soon

Visco-elastic Mouldable Compound
Features

  • Excellent immediate and permanent adhesion on steel or
    other surfaces like PE, PP, FBE

  • Long term physical, chemical, thermal and mechanically stable protection

  • Impervious to water and gases

  • Temperature range -45°C to 70°C (CZ Paste up to 50°C)

Onshore & Offshore
Rehabilitation and new build pipelines
Underground and aboveground application
CZ H PASTE

Mouldable Insulating Polymer Coating Compound for above and underground pipeline
fl anges, valves and fi ttings up to 70°C operating temperatures


Features

Benefits

 Visco-elastic, fl uid-like nature

• Conforms to any shape
• No undercreep possible
• No osmosis possible

 Amorphous, inert, no stress generation

• Will not crack, tear or breakdown

 Stable from -50°C up to 85°C max.

• Applicable at low temperatures below -15°C

 Low surface tension

• Impregnation of the surface

 Cold-fl ow technology

• Self-recovering properties
• ST 2/3 surface preparation is acceptable
• Steel roughness profi le is not critical for coating performance

 Non-toxic & no waste

• Harmless to people and the environment

 Non-crosslinked

• Full adhesion into the fi nest pores of the substrate
• Encapsulates salts and other impurities

 Excellent adhesion to itself

• Forms a monolithic coating layer

 1 component material packed as a bar

• Easy to mould by hand

STOPAQ® CZH Paste should be mechanically protected by Wrappingband CZH + other protective tapes,
sleeves, polyesters etc.
